The fully electric drum stacker is a specialized piece of equipment designed specifically for handling drums. Its electric drive enables efficient and safe vertical stacking operations. The following are its core features and technical details:
Core Functional Design: Clamping System: The front forks are equipped with anti-slip rubber pads and an electric clamping mechanism, adapting to various drum diameters (typically covering a range of 400-800mm), preventing surface damage and ensuring stable handling.
Tilting and Unloading: Some models feature a 90° electric tilt function, allowing for easy dumping of drum contents or transfer of pallets, improving storage space utilization.
Stacking Capacity: Standard models offer a stacking height range of 1.6-3.6 meters, while some customized models can reach up to 6 meters, meeting the storage and retrieval needs of three-dimensional racks.
It is widely used in many fields like the following:
The application of fully electric drum stackers in the pharmaceutical and food industries primarily addresses specific application requirements through cleanroom adaptability, precise handling, and compliance-compliant design. The following is a detailed analysis:
Pharmaceutical Industry Applications: Sterile Environment Adaptation:316L Stainless Steel Body: Made of medical-grade material, the surface is electropolished to prevent microbial growth and meet GMP cleanroom requirements.
EN1570 Certification: Compliant with EU pharmaceutical machinery standards, ensuring dust-free operation in Class 100 cleanrooms.
Explosion-Proof and Sealed Design: For handling flammable and explosive materials such as alcohol and solvents, the truck is equipped with Ex dⅡBT4 explosion-proof rating and double-sealed forks to prevent volatile leakage.
High-Precision Operation: Millimeter-Level Positioning System: Laser guidance achieves accurate alignment within ±2mm, suitable for small containers such as vials and drums.
Integrated Weighing: Select models feature a built-in electronic scale (accuracy ±0.1kg) for simultaneous weighing and handling of materials, reducing manual errors.
Operate Video:
Feature of Full Electric Oil Drum Forklift:
1. Power drive, lift and tilt for ergonomic 55 steel drums pouring;
2. Imported electrical vehicle exclusive walking control system;
3. Can be operated by one people, labor saving and high work efficiency;
4. Multi-man-machine control handles, stepless speed regulator, high-power reversing switch and manned pedal;
Product Specifications
|
Product Name |
Full Electric Oil Drum Forklift Stacker |
|
Load capacity (kg) |
450kg |
|
Max Lifting Height |
2000mm |
|
Power type |
Electric pushing and electric lifting |
|
Overall Dimensions (mm) |
2200*800*2080mm |
|
Inner width of legs |
680mm |
|
Battery(V/AH) |
24V/120AH |
Packing & Electric Drum Stacker Tilter:
Package Type: Pallet and Plastic Wrap.
Standard double-sided pallets (such as 1200mm×1000mm specifications) must meet the 2 ton load-bearing requirement, and the anti-slip design on the bottom can be adapted to the fork structure of the all-electric stacker to ensure transportation stability.
Our Advantages of Full Electric Oil Drum Forklift:
Anti-slip and Stability:
An integrated anti-slip controller maintains stability on slopes up to 10°. Structural optimization lowers the vehicle's center of gravity, allowing it to lift up to 2.5 meters on a 3.5% slope without risk of rollover.
Protective Design:
The entire vehicle is insulated to prevent electrical leakage, and equipped with an emergency brake and fork anti-fall device to ensure safe operation in humid environments.
Intelligent and Compliant:
Standard fingerprint recognition or password lock prevents unauthorized operation. Low battery automatically locks the lift function to prevent the risk of hovering.
